foldable glass for display

Foldable UTG cover glass made for foldables. The chemical strengthened down to 30~50um or 100um, depends on what your device need. We've got enough experience about thin glass: when it's correct, it works. This one bends clean—3mm to 5mm radius, 200,000 folds plus. Transmission over 91%, so the display looks like it should. Hardness Mohs 6, strong enough for daily use but thin enough to fold. Custom sizes? Tell us what you need. We'll cut it to your dimensions, edge it clean, ship it ready to process. If you're building the next foldable and need glass that bends without breaking, this is the one.

Send Inquiry

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

Next Generation - Foldable UTG Cover Glass

Overview

Why to choose UTG Cover Glass?

Phones care about fold cycles most. 200,000 is the UTG baseline-More than 5 years of usage. The glass can meet easily.

Flip phones care about bend radius. Fold more tight means thinner glass, only 30um can get you there.

The tablets care about optical clarity, the big display window magnify any distortio. 91%+ transmission and low haze keep the display looks right.

Wearables care about fit. Custom sizes mean the glass match wih the device correctly, no compromise.

What's the parameters on UTG cover glass?

The Specifications

Parameter	Value
Thickness	30µm / 50µm / 100µm (±3µm)
Max Size	Up to 300x600mm
Glass Type	Alkali-aluminosilicate

Optical Properties

Parameter	Value
Transmittance	≥91%
Haze	≤0.5%
Reflectance	≤4% (uncoated)

Mechanical Properties

Parameter	Value
Hardness	Mohs 6
Surface Compression	≥800 MPa
Depth of Layer	8-12µm

Bend Performance

Parameter	Value
Min Bend Radius	3mm (30µm) / 4mm (50µm) / 5mm (100µm)
Fold Cycles	≥200,000
Crease After Test	≤0.05mm

Surface Quality

Parameter	Specification
Scratch-Dig	20/10 max
Roughness (Ra)	≤0.5nm

Dimensional Tolerances

Parameter	Tolerance
Length/Width	±0.1mm
Thickness	±3µm
Hole Position	±0.1mm

Environmental Durability

Test	Result
Temp Range	-40°C to 85°C
Humidity	85°C/85% RH, 1000hrs pass

Available Coatings

Coating	Benefit
AF	Anti-fingerprint, easy clean
AR	Anti-reflection, better readability

Aluminosilicate UTG Options

For higher strength requirements, aluminosilicate UTG is available in:

0.100mm, 0.145mm, 0.210mm, 0.250mm, 0.330mm

Other types of glass materials

What's the Applications?

Consumer Electronics

Smartphones, tablets, laptops,wearables

Industrial & Commercial Displays

Control panels, kiosks, POS systems, and outdoor advertising display.

Automotive Displays

Instrument clusters, navigation display, and infotainment systems.

Medical Equipment

Diagnostic monitors and touch-sensitive medical interfaces.

Public & Outdoor Displays

Digital signage, ATMs, vending machines, and ticketing terminals.

Material & Processing Options

UTG cover glass (Ultrathin Glass) is an alkali-aluminosilicate glass specifically formulated for thinness and flexibility.

Unlike standard cover glass, it's designed from the ground up to bend without breaking.

Available Processes:

Anti-Glare Etching – Chemical or physical. Scatters light so dispay window stay readable in bright conditions. Haze is controlled for uniform diffusion.

Nano Coating – Repels fingerprints and water. Smooth swipe, easy clean. Lasts because it bonds at molecular level.

Strengthening – Thermal tempering or chemical ion exchange. Builds surface compression so glass survives drops. Breaks safer if it fails.

Optical Lamination – Bonds cover glass to sensors or OLED. No air gap, better touch response, colors stay true.

Precision Finishing – Cut to size, edges polished. Holes, notches, corners within ±0.1mm. No sharp edges, no chips.

Key Features & Advantages

Enhanced Visual Clarity

Increase high contrast and color fidelity.

Scratch & Wear Resistance

Surface hardness up to 8-9H (Mohs scale).

Anti-Fingerprint & Easy Cleaning

Optional oleophobic and hydrophobic coatings.

High Light Transmittance

Up to 92%, ensuring bright and vivid displays.

Customization Surface Roughness

Available in matte, semi-matte, and glossy finishes.

UV & Chemical Resistance

Suitable for long-term outdoor or industrial use.

Cleaning

Use isopropyl alcohol – 70% to 90% IPA with lint-free wipes. No acetone, no harsh solvents. They can attack coatings.

Gentle pressure – UTG is thin. Press too hard during cleaning and you risk micro-cracks. Wipe lightly, let the solvent do the work.

One direction – Don't scrub in circles. Linear motion across the surface. Reduces risk of scratching.

Dry immediately – Don't let cleaning solution evaporate on the surface. It leaves residues that affect bonding later.

Customization & Service

We provide UTG cover glass OEM/ODM customization to meet your specific project requirements.

Customization Options:

Size, thickness (25-200um)

Shape, hole drilling, and edge design

Surface gloss and haze level adjustment

Logo printing and color coating

Optical bonding and lamination integration

Quality Assurance & Testing

Every piece of UTG cover glass undergoes strict quality control and optical testing, including:

Light transmittance & haze measurement

Surface roughness & uniformity inspection

Scratch and hardness testing

Environmental & temperature endurance testing

All products comply with RoHS, REACH, and ISO9001 standards.

FAQ

Q:What's the foldable glass and difference between regular glass?

A:The foldable glass is a kind of ultra thin flexible glass for fodable phones/tablets, designed to bend repeatedly without break. Dislike regular glass(Gorilla Glass for example), it's around 30 microns thick(thinner than a human hair) and chemically strengthened. It balances flexibility with glass-like scratch resistance and clarity-way better than early foldables' plastic/CPI films.

Q:Can foldable glass really durable and if it can handle daily use?

A: Yes, it is but not indestrutible.

The most of UTG withstands 200,000+ folds(Around 5 years of 100 times daily uses) in perfect condition.

It's scratch-resistant (~Mohs 6, handles keys/coins), but hard drops on the fold or sharp impacts can crack it.

Extreme temperatures (too cold/hot) also make it more brittle.

Q:Why foldable phones with UTG still have a protective film on top?

A:That film is part of the design, not a throwaway layer.

UTG needs extra protection from micro-scratches, dust, and minor impacts- the thin polymer film works with the glass.

Don't peel it (can damage glass/touch sensitivity), get it replaced by the manufacturer if scratched/bubbly (some offer free one-time replacement).

Q:I heard foldable glass breaks easily in cold weather-Is that true?

A:It's not that it breaks easily but cold temperatures do make it more fragile.

Here's why: foldable glass (and the materials around it, like the hinge lubricant) changes at low temps-below 0°C (32°F).

Logistics & Packaging

Packaging

Multi-layer protective packaging to prevent scratches or breakage.

Shipping

Sea, air, train, special line and express.

Lead Time

10-15 working days depending on order volume.

Samples

Free for stock samples, charge for custom samples.

After-Sales Support

Our professional team provides full technical support, from material selection to installation guidance. If any product issue arises, we offer prompt replacement or refund service to ensure customer satisfaction.
